JENSEN A530

The Jensen A530 is a great all-round chipper, powerful, robust and easy to manoeuvre due to it’s 750kg towing weight. The 270 degree rotating chute ensures easy chip projection in any direction.

Jensen PTO machines boast outstanding performance and reliability, completely self contained with their own hydraulic system, they only need drive and electrical supply from the power unit to work. The PTO version of the A530 can be operated with a compact tractor, starting at 22kW (30hp) of PTO drive power.

Compact, easy to maintain and highly reliable, the A530 is a true favourite in the industry.

✔ Towable

✔ PTO

Jensen A530: Features

  • Robust housing with silencing equipment and sound reducing paint
  • 270 degree rotating chute
  • Integrated storage box
  • Hydraulic infeed rollers
  • Safety bar
  • Optional electronic safety sensors for immediate switch off
  • Fitted tool box with comprehensive toolkit included
  • Control box to record hours and servicing intervals
  • Galvanised steel chassis

Road Towable Version

  • 22hp diesel engine
  • single axle 80km/h
  • fixed drawbar with towing eye or ball hitch



PTO Version

  • 3 point linkage cat. I
  • Independent hydraulic system

Jensen A530: Specifications

TECHNICAL DATA Towable PTO
Capacity 130mm 130mm
Engine 17.5 kw / 22 HP 30hp power required
Feed Roller Aperture (W x H) 210 x 130mm 210 x 130mm
Adjustable Chip Length 5-20mm 5-20mm
Flywheel Dimensions 600 x 25mm 600 x 25mm
Flywheel Weight 70kg 70kg
Number of Blades 2 2
Capacity ca. 12m3/h ca. 12m3/h
Infeed Hopper (W x H) 860 x 740mm 860 x 740mm
Dimensions (L x W x H) 3000 x 1450 x 2600mm 2200 x 1200 x 2500mm
Weight  750kg  500kg
